Approvals
Specification & Standard
Size Range
As Per Standard
Ambient Temperature
-20°C ~80°C
Material
Aluminium Pressure Die Cast
Conduit Connection
1/2” NPT
Mounting Bracket
Namur VDI / VDE 3845,ISO 5211
Terminal
8 Points
Switch Range
AC 250V 3A,125V 5A,DC 250V 0.2A,125V 0.4A,30V 4A
Enclosure Protection
IP 67
Features & Benefits
1 – Visual Position Indicator
2 – 6 Contacts Of Terminal Ports
3 – Compatibility With Any Rotary Motion Actuator ISO 5211
4 – Easy Adjustment Of Cam Position
5 – Dual 1/2″ Conduit Entries
Get in touch with our team at +91 9099477256 to receive the Dimension Table
