Approvals
‘”aira” Offers A low weight wafer type valve (body:aluminum) Which is optimally suited for applications with soft seating (Nitrile / EPDM) requirements. Suitable for all water application, like HVAC, Plumbing, Fire Fighting, Water Treatment Plant.
Specification & Standard
Design & Manufacturer
API 609 Category A/BS 5155/MSS SP - 67/C - 504
Valve Face To Face Dimension
Short Wafer As per ISO 5752 Tab 5 API 609 Category A
Top Flange Drilling
ISO 5211 II
Flange Standard Conformity
ANSI 150, DIN PN 6/16
Inspection & Testing
API 598/BS EN - 12266 - 1
Size Range
1.1/2" To 12" (40 MM To 300 MM)
Temperature Range
-50' C TO 300' For Soft Seated Valves. Contact Works For Special Requirement
Pressure Class
150#
Media
Water
Leakage Class
Class VI/Bubble Type Shut Off
Body Material
Aluminium Pressure Die Cast
Disc Material
CF8/CF8M
Seat Material
EPDM
End Connection
Wafer Type Aluminium Pressure Die Cast Butterfly Valve
Design Standard
API 609 Category A/IS : 13095/BSEN 593
Flange Drilling
ASME B16.5/16.47 Series A Class 150.
Certification
Design CE Approved, SIL3 Approved, POD.
Face To Face
ASME B 16.10, Other F To F Available On Request
Features & Benefits
The aira Centric Aluminium Pressure Die Cast Butterfly Valve is designed for lightweight yet durable performance.
1 – Centric Design: Ensures smooth operation with a central disc arrangement, reducing friction and wear.
2 – Aluminium Die Cast Construction: Offers a lightweight yet strong and corrosion-resistant body, ideal for various applications.
3 – Efficient Sealing: Provides reliable shut-off with minimal leakage, thanks to advanced sealing technology.
4 – Compact and Lightweight: Easy to handle and install, making it suitable for space-constrained environments.
5 – Versatile Applications: Perfect for industries such as water treatment, HVAC systems, and general industrial use.
Fire Safe Design
Direct Mounting As Per ISO 5211
Centric
Aluminium Butterfly Valve
Dimension Table
Centric
Aluminium Butterfly Valve
Dimension Table
