“aira” Offers 2/2-way Globe Control Valve, Pneumatically Operated, N/C & N/O universal actuators with modular universal accessory program up to control heads. They have a stainless steel body and are available with the choice of flange-, threaded- and weld-end port connections. Specifically engineered for reliable control in applications where accuracy is paramount, Fine chemical pressure and flow control High accuracy test bench equipment, Food, beverage and pharmaceutical CIPSIP and auxiliary processes with steam Pharmaceutical Sterilizers, Precision distillation apparatus, Sterile Packaging Machinery.
Specification & Standard
Size Range
15MM To 50MM
Tempreature Range
PTFE 180°C / CFT 220°C
Pressurre Class
Upto 10 BAR
Shutoff Rating
Tight Shut off
Body Style
Glob Body
Flange Drilling
150#
Certification
CE Approved
Body Materials
S. S - 304, S. S - 316-L
Stem Materials
S. S - 304
Seat Materials
PTFE, CFT, GFT
Plug Materials
S. S - 304
Design Standard
Manufacture - Standard
Testing Standard
API - S98, PN10
Face To Face
Manufacture - Standard
Leakage
As Per ANSI B16, 16.104 Leakage Class VI Shut Off Tight / Bubble Tight
Applications
Air / Water / Oil / Gas / Steam & Chemical
Features & Benefits
1 – Globe Valve ( On/Off Control ).
2 – Provides Precise Control Of Fluid Flow With On/Off Functionality.
3 – Features A Globe-Shaped Body For Effective Flow Regulation And Minimal Pressure Drop.
4 – Ideal For Applications Requiring Reliable And Accurate Shut-Off Or Flow Control.
5 – Made From High-Quality Materials For Durability And Long Service Life.
6 – Suitable For Various Industrial Processes And Systems Where Control And Isolation Of Flow Are Required.
Globe Type On-Off
Screwed Control Valve
Dimension Table
Globe Type On-Off
Screwed Control Valve
Dimension Table
