Double Offset

Rubber Seated Wafer Type Butterfly Valve

Size Range
3" To 60" (80MM To 1500MM)
Temperature Range
Upto 220°C
Working Pressure
PN 50
Inquiry Now

Double Offset Rubber Seated Wafer Type Butterfly Valve

Size Range
3" To 60" (80MM To 1500MM)
Temperature Range
Upto 220°C
Working Pressure
PN 50
Inquiry Now

Approvals

“aira” Offers Double Offset Rubber Seated Wafer Butterfly Valve offers efficient flow control with its double offset design for reduced friction and extended life. Featuring a tight-sealing rubber seat and wafer-type construction, it ensures minimal leakage and easy flange installation. Ideal for water, wastewater, and various fluid systems, this valve combines durability and cost-effectiveness.

Specification & Standard

Size Range

3" To 60" (80MM To 1500MM)

Tempreature Range

Upto 220°C

Pressurre Class

PN 50

Shutoff Rating

Tight Shut Off

Body Style

Wafer Type

Flange Drilling

150#, 300#, AWWA, Series-A, Series-B, EN 1092-1, EN 1092-2

Body Materials

WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY - 20

Stem Materials

SS 304 / 316 / 410 / 17-4 PH / 316L / NITRONIC - 50 / DUPLEX 4A / 5A / 6A / 7A

Seat Materials

EPDM, EPDM - H, VITON

Disc Materials

WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY - 20

Design Standard

BSEN 593, ISI 3095, API 609, AWWA C 504

Testing Standard

API 598, BSEN - 12266-1, AWWA C 504

Face To Face

API - 609, BSEN 558, AWWA C 504 / 516

End Connection

150#, 300#

Features & Benefits

1 – Double Offset Design: Reduces friction and wear, enhancing performance and extending valve life.

2 – Rubber Seat: Provides a reliable, tight seal to minimize leakage.

3 – Wafer Type Construction: Facilitates easy installation between flanges and saves space.

4 – Versatile Application: Suitable for water, wastewater, and other fluid handling systems.

5 – Durability: Designed for long-lasting performance and cost-effectiveness.

6 – Compact and Lightweight: Ideal for various industrial and commercial settings.

Direct Mounting As Per ISO 5211

Double Offset

Rubber Seated Wafer Type Butterfly Valve

Dimension Table

Double Offset

Rubber Seated Wafer Type Butterfly Valve

Dimension Table
