3 Piece

Flanged End Ball Valve

Size Range
1/2" To 14" Flanged
Temperature Range
PTFE : Upto 180°C/ PEEK : 250°/ RPTFE : Upto 220°C/ AIRA250
Working Pressure
As Per Pressure Class
Inquiry Now

3 Piece Flanged End Ball Valve

Size Range
1/2" To 14" Flanged
Temperature Range
PTFE : Upto 180°C/ PEEK : 250°/ RPTFE : Upto 220°C/ AIRA250
Working Pressure
As Per Pressure Class
Inquiry Now

Approvals

“aira” Offers Investment Casting WCB / CF8 / CF8M / CF3M Ball Valve Floating In Three Piece Design. Engineered For Multiple On/Off Operations In The Down Stream.

Specification & Standard

Design & Manufacturer

ASME B16.34 / BS EN ISO 17292

Valve Face To Face Dimension

ASME B16.10/ 150#

Inspection & Testing

API 598/ ISO-5208/ BS EN 12266-1

Size Range

1/2" to 14"

Tempreature Range

-50' C To 300' For Soft Seated Valves. Contact Works For Special Requierment (On Request)

Ball Material

CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M, INCONEL

Ball Type

Hollow & Solid

Certification

Design CE Approved, SIL3 Approved, IBR Approved, POD Approved & Fire Safe Approved

Leakage Class

ISO 5208 Class VI/ ASME B16.104/ ANSI FCI 70-2( BUBBLE TIGHT SHUTOFF)

End Connection

ASME B16.5 CLASS 150/300 FOR FLANGED

Pressurre Class

150#

Media

Air/ Water/ Oil & Gas Etc…

Body Material

CF8, CF8M, CF3M, SS 304L, WCB, DUCTILE IRON(DI), DUPLEX, HAST ALLOY, MONEL

Stem Material

AISI 410, AISI 304, AISI 316, AISI 304l, AISI 316L, DUPLEX 2205, DUPLEX 2507, MONEL

Seat Material

PTFE, RPTFE, CFT, GFT, MODIFIED PTFE, AIRA-250, NYLON, DEVLON, PEEK

Flange Drilling

ASME B16.5 Class 150#/ 300 #/ Din/ Jis

Features & Benefits

1 – High Cycle Life.

2 – Anti static Design & Fire Safe Design As Per API 607.

3 – Blow Out proof Stem.

4 – Locking Handle Available.

5 – ISO 5211 Mounting Pad Available.

6 – V-type Cheuron Gland Packing, Which Leads To Zero Leak After Thousand Of Cycle.

Direct Mounting As Per ISO 5211

Anti Static Mechanism

Fire Safe Design

3 Piece

Flanged End Ball Valve

Dimension Table

3 Piece

Flanged End Ball Valve

Dimension Table
